8 Antennas Full-Band Cell Phone Signal shielding instrument Outdoor Jammers 8341CA-8B

8341CA-8B eight route full-band cell phone signal shielding instrument:

1. The function and characteristics:
   1. *Effective shielding CDMA , GSM ,  td-scdma (netcom big informed), DCS (1800 MHZ), PHS (1900 MHZ), 3 G, 4 G cell phone signal and WIFI (WLAN), 2.4 G/bluetooth communication, wireless network (QQ and weibo, etc.), a wireless signal
      *Green environmental protection, is far lower than the national standard of electromagnetic field intensity, without any impact to the human body.It is a Good Quality Power Signal Jammer.
      *Unique cooling vents and double fan design, ensuring long time continuous and stable work.
      * Built-in industrial-grade Power switching Power supply, the stability, accuracy of the signal
      *Simple operation, correct installation antenna, the Power can be run automatically
      * Slow start function , effectively avoid appear lighter phenomenon when the phone is switched on
      * Choose imported high-performance integrated circuit and SMT components, and adopts imported fully automatic SMT machine
      Reflow welding machine processing and assembly line production, quality, stable performance
      *Fine division of each channel, only interfere with the downlink, communication will not cause interference

Technical indicators:
Electromagnetic field strength Measured values are much lower than the "Regulations for electromagnetic radiation protection limits" (GB8702-88), up to national standard.

Product features:
*To 30 meters, effective shielding distance is adjustable, the scene can be arbitrary debugging)
*3 g/GSM/CDMA/DCS/PHS shielding five road spectrum
*Can work 24 hours continuously
*Apply to all kinds of places
*Use high heat dissipation white aluminum shell surface can according to customer needs or silk screen logo free provide printing services
*Transmitted Power 15 w, around 3 w per antenna application places: all places

Performance parameters:

Type B WIFI + GPS:

The output end	Working frequency	Average output Power	Channel output Power
CDMA	870-880MHz	35dBm	8dBm/30KHz(min)
DCS/PHS	930-960MHz	35dBm	5dBm/30KHz(min)
3G1	1805-1918MHz	33dBm	2dBm/30KHz(min)
4G1	2010-2145MHz	33dBm	2dBm/30KHz(min)
4G2	2400-2500MHz	33dBm	2dBm/30KHz(min)
3G2	1570-1580MHz	33dBm	2dBm/30KHz(min)
The Power supply:AC220V-DC12V          Block radius: 2-50 m @ sight operator network signal
1. Available VHF walkie talkie or wireless remote control frequency band.   2. UHF optional intercom or CDMA450M spectrum. 3. We provide the function of three kinds of shielding options (6) a/B/C please carefully review parameters, At the same time because the price of different configuration may differ, please select from the product list you need the correct model. 4. A configuration block the GPS signal model, we can also provide car Power charger..
Screen single packing weight: 3.2Kg            Size (width x height (deep) : 51 x 140 x 350 mm

GPS + 8 A WIFI + 4 g type:

The output end	Working frequency	Average output Power	Channel output Power
CDMA	870-880MHz	35dBm	8dBm/30KHz(min)
GSM	930-960MHz	35dBm	5dBm/30KHz(min)
DCS/PHS	1805-1918MHz	33dBm	2dBm/30KHz (min)
3G	2010-2145MHz	33dBm	2dBm/30KHz (min)
WIFI 2.4G	2400-2500MHz	33dBm	2dBm/30KHz (min)
GPS	1570-1580MHz	33dBm	2dBm/30KHz (min)
The Power supply:AC220V-DC12V          Block radius: 2-50 m @ sight operator network signal
Screen single packing weight: 3.2Kg            Size (width x height (deep) : 51 x 140 x 350 mm
*Available VHF walkie talkie or wireless remote control frequency band.   *UHF optional intercom or CDMA450M spectrum. *We provide the function of three kinds of shielding options (6) a/B/C please carefully review parameters, At the same time because the price of different configuration may differ, please select from the product list you need the correct model. *A configuration block the GPS signal model, we can also provide car Power charger..
